Photo Frame Joining Machine

The Photo Frame Joining Machine is specially designed for joining wooden, plastic, or composite frame corners at perfect angles using V-nails or staples. Whether you’re working in a professional frame shop or running a small-scale operation, this machine offers clean joints, easy operation, and consistent results. With adjustable height, angle control, and foot or pneumatic actuation options, it guarantees quality frame assembly for photos, artworks, certificates, and more.

Product Features:

• Precision corner joining with minimal gap
• Adjustable for different frame thicknesses
• Works with standard V-nails
• Durable and low-maintenance design
• Ideal for custom or bulk frame production

Specifications:

• Product Name – Photo Frame Joining Machine
• Frame Material Support – Wood, MDF, PVC, Plastic Composite
• Joining – Angle 90° (Fixed), adjustable clamp positions
• V-Nail Sizes – Supported 5mm, 7mm, 10mm, 12mm, 15mm (varies)
• Actuation Method – Manual foot pedal or Pneumatic (air)
• Clamp Type – Adjustable vertical & horizontal clamps
• Base Material – Reinforced cast aluminum or steel
• Dimensions (LxWxH) – Approx. 60 x 50 x 45 cm
• Weight – 18–25 kg depending on model
• Application – Photo frames, canvas frames, certificate frames
• Warranty – 6 – 12 months (based on vendor)

Installation Instructions:

• Unbox; remove transit locks/foam; confirm accessories (left/right fences, backstop, corner clamp, foot pedal, V-nail head/magazine, tool kit).
• Assemble and level the floor stand (or mount on a rigid bench).
• Fit left/right fences and backstop; square to 90° with a try-square; tighten screws.
• Install the V-nail driver head and magazine; load correct V-nail size (e.g., 5–15 mm) for your moulding.
• Pneumatic models: connect air line with filter/regulator; set 0.5–0.7 MPa (70–100 psi); check for leaks.
• Electric models: connect 220–240 V; verify foot pedal/solenoid; test E-STOP.
• Set clamp height/pressure for moulding thickness; adjust table height/stacker if fitted.
• Join two test offcuts: clamp → test fire V-nail into scrap → inspect the corner; fine-tune fence alignment/pressure.
• Lightly lubricate the driver head as per manual; keep work area clear.
• Installation support available on request.

Shipping & Delivery Information:

• Ships within 7–10 business days across Africa.
• Protective crating; includes stand/assembly kit.
• Nationwide & international delivery available.
